Connect/Gateway panel guide: Notifier ID3000

Overview

Nimbus supports connection to either an Isolated RS232 Interface or the Mainboard RS232 Port.

Equipment required

• A Nimbus Connect or Fixed Gateway device

• 3 core screened data cable

AND

• Notifier ID3000 Isolated RS232 Interface PCB (PN:020-478)

OR

• A Nimbus supplied RS232 Male 'D' Type panel connector (part no 201-304-01)



Panel configuration

1. Navigate the menu according to the required connection method

   1. User Menu

   2. Option 6 (enter level 3 password)

   3. User Menu

   4. Configuration

   5. Option 6: Panel Settings

   6. Option 17: Isolated RS232 Interface

      ...or...

      Option 18: Mainboard RS232 Port

2. Configure as below

   1. Type: 3rd Party RS232

   2. Baud rate: 9600

   3. Protocol Version: 011A Protocol

   4. Port Setup: Full Duplex

   5. Controls: Disabled

   6. Fault Monitoring: Disabled

   7. Suspend Time Limit: 0 & Not Logged

   8. Incoming Data Timeout: 1 Second

   9. Allow Time Sync from 3rd Party: No

Wiring

Isolated RS232 Interface

Using 3 core screened data cable wire to the Nimbus RS232 as follows.

Mainboard RS232 Port

Connect the Nimbus Male 'D' connector to then RS232 port on the mainboard.

Using 3 core screened data cable wire to the Nimbus RS232 as follows.

Troubleshooting

If Nimbus appears to be recording each event 10 times, check the connection between Nimbus Connect and Panel, specifically the Nimbus Connect TX to Panel RX. A poor connection will result in the acknowledgement from the Nimbus Connect to Panel not being received and 10 copies of each event being reported.
